Starter

Description

Easy Build AMD Ryzen 3 3200G / A320 / 8GB / 240GB / 700Watts / Case

A320M-A Pro Socket Am4 Ddr4 Motherboard

• Model: A320M-A PRO
• CPU Socket Type: AM4
• CPU Type: Supports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4
• Chipset: AMD A320
• Number of Memory Slots: 2×288pin
• Memory Standard: Supports 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz (by A-XMP OC MODE)
• Support DDR4 3200(OC)/ 2933(OC)/ 2667/ 2400/ 2133/ 1866 MHz (by JEDEC)
• Maximum Memory Supported: 32GB
• Channel Supported: Dual Channel
• PCI Express 3.0 x16:
• 1 x PCIe 3.0 x16 slot:
• 1st, 2nd and 3rd Gen AMD Ryzen: Supports x16 speed
• Ryzen with Radeon Vega Graphics, 2nd Gen AMD Ryzen with Radeon Graphics, A-series, Athlon X4: Supports x8 speed
• AMD Athlon with Radeon Vega Graphics: Supports x4 speed
• PCI Express x1: PCIe 2.0 x1 slot
• SATA 6Gb/s: 4 x SATA 6Gb/s
• SATA RAID: 0/1/10
• Onboard Video Chipset:
• Supported only by CPU with integrated graphic:
• 1 x DVI-D port supports a maximum resolution of 1920×1200@60Hz
• 1 x HDMI 1.4 port supports a maximum resolution of 4096×2160@24Hz
• Only support when using the processor with Graphicss
• Maximum shared memory of 2048MB
• Audio Chipset: Realtek ALC892
• Audio Channels: 7.1 Channels
• LAN Chipset: Realtek 8111H
• Max LAN Speed: 10/100/1000Mbps
• Back I/O Ports: 1 x DVI-D / 1 x HDMI / 1 x LAN (RJ45) / 2 x PS/2 / 2 x USB 2.0/1.1 / 3 x Audio Jacks / 4 x USB 3.2 Gen 1
• Onboard USB: 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1 x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports)
• Other Connectors:
• 1 x 4-pin CPU fan connector
• 1 x 4-pin system fan connector
• 1 x Front panel audio connector
• 2 x Front panel connectors
• 1 x TPM module connector
• 1 x Chassis Intrusion connector
• 1 x Serial port connector
• 1 x Clear CMOS jumper
• Form Factor: Micro ATX
• Dimensions (W x L): 8.9″ x 7.4″
• Power Pin: 1 x 24-pin ATX main power connector
• 1 x 4-pin ATX 12V power connector

Ryzen 3 Processor

• CPU Socket Type: Socket AM4
• # of Threads: 4
• Operating Frequency: 3.6 GHz
• Max Turbo Frequency: 4.0 GHz
• L1 Cache: 384KB
• L2 Cache: 2MB
• L3 Cache: 4MB
• Manufacturing Tech: 12nm
• Memory Types: DDR4 2933
• Memory Channel: 2

8GB Ddr4 Memory

• Frequency: 3200
• Data Transfer: 25,600 MB/s
• Bandwidth: (PC4 25600)
• Latency: CL22-22-22-52
• Voltage: 1.2V
• Dimensions: 32(H) x 134(L) x 6.5(W)mm
• Heat Spreader: Aluminum heat spreader

240gb Solid State Drive

• Brand: Kingston
• Series: A400 Series
• Capacity:  240GB and 960GB
• Specific Uses For Product Business, personal
• Connectivity Technology: SATA
• Hard Disk Form Factor: 2.5 Inches
• Digital Storage Capacity: 240 GB
• Compatible Devices: Backwards compatibility to SATA Rev. 2.0 (3Gb/s)
• Hard Disk Interface: Serial ATA
• Form factor: 5″ & M.2 2280
• Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s)
• NAND: 3D
• Baseline Performance:
• Data Transfer (ATTO): 240GB — up to 500MB/s Read and 350MB/s Write
• Power Consumption: 195W Idle / 0.279W Avg / 0.642W (MAX) Read / 1.535W (MAX) Write
• Storage temperature: -40°C~85°C
• Operating temperature: 0°C~70°C
• Dimensions: 0mm x 69.9mm x 7.0mm (2.5”), 80mm x 22mm x 1.35mm (M.2)
• Weight: 6.7g (240GB – M.2)
• Vibration operating: 17G Peak (7–800Hz)
• Vibration non-operating: 20G Peak (10–2000Hz)
• Life expectancy 1 million hours MTBF
• Total Bytes Written (TBW): 240GB: 80TB

Gaming PC Case

• Power Supply Position inside bottom of the case
• Cooler Fan cooler fan’s price not included
• Cooler Fan Support: front panel 3*120mm/top 2*120mm/rear 1*120mm
• USB I/O 3.0*1+1.0*2+HD.AUDIO
• HDD/SSD HDD*1+SDD*1
• Motherboard Support ATX/Micro-ATX
• Material & Thickness: 0.45mm SPCC/SGCC
• Size without front panel and legs（L*W*H): 335X200X435mm
• Size with front panel and legs（L*W*H): 375X200X450mm
• Package size（L*W*H): 485X252X430mm
• Net Weight: 3.9KG
• Gross Weight: 4.6KG
• PCI Slots: 6
• VGA length limit 320mm
• CPU height limit 1705m

700 watts Power Supply

• Volts: ATX 12V
• Watts: 700W power supply
• PIN: 24+4 +4 pin + 2 molex 2 sata power Big Fan
• Compliant with ATX 12V version 2.2
• Compliant with latest multi-core CPU motherboards and high-end graphic cards
• Dual 12V rails design provides independent output currents for CPUs
• Quiet mode Technology
• Over-current protection
• Over-power protection
• Short circuit protection
• 100% full load burn-in
