Description

Specifications
Manufacturer (OEM) Seasonic
Max. DC Output 650W
Efficiency 80 PLUS Gold, ETA-A (88-91%)
Noise LAMBDA-S+ (35-40 dB[A])
Modular ? (Fully)
Intel C6/C7 Power State Support ?
Operating Temperature (Continuous Full Load) 0 – 50C
Over Voltage Protection ?
Under Voltage Protection ?
Over Power Protection ?
Over Current (+12V) Protection ?
Over Temperature Protection ?
Short Circuit Protection ?
Surge Protection ?
Inrush Current Protection ?
Fan Failure Protection ?
No Load Operation ?
Cooling 120mm Fluid Dynamic Bearing Fan (S1201512HB)
Semi-Passive Operation ?
Dimensions (W x H x D) 128 x 66 x 128mm
Weight 1.15 kg (2.54 lb)
Form Factor SFX-L, EPS 2.92
Warranty 10 Years
Power Specifications

Rail 3.3V 5V 12V 5VSB -12V
Max. Power Amps 20 20 54 3 0.3
Watts 100 648 15 3.6
Total Max. Power (W) 650
Cables & Connectors
Modular Cables
Description Cable Count Connector Count (Total) Gauge In Cable Capacitors
ATX connector 20+4 pin (360mm) 1 1 18AWG No
4+4 pin EPS12V (400mm) 1 1 18AWG No
6+2 pin PCIe (400mm+100mm) 2 4 18AWG No
SATA (300mm+200mm+100mm) 2 6 18AWG No
4 pin Molex (300mm+200mm+200mm) 1 3 18AWG No
AC Power Cord (1370mm) – C13 coupler 1 1 18AWG –
