Description
| Graphics Processor | |
| GPU Name | GA102 |
| GPU Variant | GA102-200-K1-A1 |
| Process Size | 8 nm |
| Transistors | 28,000 million |
| Die Size | 628 mm² |
| Graphics Card | |
| Generation | GeForce 30 |
| Bus Interface | PCIe 4.0 x16 |
| Clock Speeds | |
| Base Clock | 1440 MHz |
| Boost Clock | 1710 MHz |
| Memory Clock | 1188 MHz |
| 19 Gbps effective | |
| Memory | |
| Memory Size | 10 GB |
| Memory Type | GDDR6X |
| Memory Bus | 320 bit |
| Bandwidth | 760.3 GB/s |
| Render Config | |
| Shading Units | 8704 |
| TMUs | 272 |
| ROPs | 96 |
| SM Count | 68 |
| Tensor Cores | 272 |
| RT Cores | 68 |
| L1 Cache | 128 KB (per SM) |
| L2 Cache | 5 MB |
| Theoretical Performance | |
| Pixel Rate | 164.2 GPixel/s |
| Texture Rate | 465.1 GTexel/s |
| FP16 (half) performance | 29.77 TFLOPS (1:1) |
| FP32 (float) performance | 29.77 TFLOPS |
| FP64 (double) performance | 930.2 GFLOPS (1:32) |
| Board Design | |
| Slot Width | Dual-slot |
| TDP | 320 W |
| Suggested PSU | 700 W |
| Outputs | 1x HDMI |
| 3x DisplayPort | |
| Power Connectors | 1x 12-pin |
| 2x 8-pin | |
| Board Number | PG132 SKU 10 |
| Graphics Features | |
| DirectX | 12 Ultimate (12_2) |
| OpenGL | 4.6 |
| OpenCL | 2 |
| Vulkan | 1.2 |
| CUDA | 8.5 |
| Shader Model | 6.5 |
