Description
Asus TUF X570 Plus Wifi Gaming Socket Am4 Ddr4 Motherboard
Product Specifications
- CPU AMD AM4 Socket 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/AMD Ryzen™ 2nd Generation/3rd Gen AMD Ryzen™ Processors
- Chipset AMD X570
- Memory
- 3rd Gen AMD Ryzen™ Processors
- 4 x DIMM, Max. 128GB, DDR4 4400(O.C)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
- 2nd Gen AMD Ryzen™ Processors
- 4 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
- 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
- 4 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
- Dual Channel Memory Architecture
- ECC Memory (ECC mode) support varies by CPU.
- Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
- Graphic
- *Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
- *Multi-VGA output support : HDMI/DisplayPort ports
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz
- Supports DisplayPort with max. resolution 4096 x 2160 @ 60 Hz
- Multi-GPU Support
- 3rd and 2nd Gen AMD Ryzen™ Processors
- AMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation Processors
- Supports AMD CrossFireX™ Technology
- Expansion Slots
- 3rd Gen AMD Ryzen™ Processors
- 1 x PCIe 4.0 x16 (x16 mode)
- 2nd Gen AMD Ryzen™ Processors
- 1 x PCIe 3.0 x16 (x16 mode)
- 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
- 1 x PCIe 3.0/2.0 x16 (x8 mode)
- AMD X570 chipset
- 1 x PCIe 4.0 x16 (max at x4 mode)
- 2 x PCIe 4.0 x1
- Storage
- 3rd Gen AMD Ryzen™ Processors :
- 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
- 2nd Gen AMD Ryzen™ Processors :
- 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support
- AMD X570 chipset :
- 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support
- 8 x SATA 6Gb/s port(s)
- Support Raid 0, 1, 10
- LAN
- Realtek® L8200A
- ASUS Turbo LAN Utility
- TUF LANGuard
- Wireless Data Network
- Intel® Wireless-AC 9260
- Wi-Fi 802.11 a/b/g/n/ac
- Supports dual band frequency 2.4/5 GHz
- Supports MU-MIMO
- Supports channel bandwidth: HT20/HT40/HT80/HT160
- Bluetooth Bluetooth® 5.0
- Audio
- Realtek® ALC S1200A 8-Channel High Definition Audio CODEC
- Audio Feature:
- Exclusive DTS Custom for GAMING Headsets.
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
- Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.
- USB Ports
- 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :
- 4 x USB 3.2 Gen 1 port(s) (4 at back panel, )
- AMD X570 chipset:
- 3 x USB 3.2 Gen 2 port(s) (3 at back panel, , 2 x Type-A+1 x USB Type-CTM)
- AMD X570 chipset:
- 2 x USB 3.2 Gen 1 port(s) (2 at mid-board)
- AMD X570 chipset:
- 4 x USB 2.0 port(s) (4 at mid-board)
